General
The DDS238-1 ZN model is equipped with a digital-only display and boasts an accuracy class of 1.0. It operates within a broad temperature range of -25°C to 70°C, consuming minimal power of less than 2W at 10VA. The start current for this model is 0.004Ib.
Adhering to the executive standard IEC62053-21 DIN 43880, it offers a passive pulse output with a duration of 80 ± 5 ms. The working temperature range matches the operating temperature, spanning from -25°C to 70°C. With an IP20 grade, it ensures robust protection. Additionally, it can withstand an AC voltage of 4000V/25mA for 60 seconds.
Technical Parameters
| Model Number | DDS238-1 ZN |
| Display Type | Digital Only |
| Accuracy Class | 1.0 |
| Operating Temperature | -25 °C ~70°C |
| Power consumption | <2W/10VA |
| Start current | 0.004lb |
| Executive standard | IEC62053-21 DIN 43880 |
| Pulse output | Passive pulse, 80 ± 5 ms |
| IP grade | IP20 |
| AC voltage withstand | 4000V/25mA for 60s |
Yueqing Lovadon Electric Co., Ltd.
