General
200 Amps, 600 V AC.
Line and load connector range: #6–350 Cu-Al.
Heavy-duty tinned copper jaws with reinforced clips.
Complete with centre neutral bar.
NEMA 3R enclosure construction; 1.2 mm thick (#18 gauge) or 1.5 mm thick (#16 gauge) galvanized steel
sheet, finished with electrostatically applied baked gray epoxy powder coating.
Ample gutter space for easy wiring.
Convenient knockouts on sides, rear and bottom.
Lay-in type terminals with pressure plates for simple wiring connections.
Fixed hubs available in sizes 1/2" to 2-1/2" as an option.
Yueqing Lovadon Electric Co., Ltd.
