LCB2L-63 2P RCCB Circuit Breaker with 2P Pole 10ka Breaking Capacity 40a Miniature Earth Leakage Circuit Breaker

The ‌LCB2L-63 2P is a Residual Current Circuit Breaker. It features a rated voltage of ‌230/400V‌ and a rated current range of ‌10A-63A‌. Suitable for ‌50/60Hz‌ frequency, it offers protection against electric leaks and is compliant with ‌IEC61008-1‌ standards. Made of ‌PA66/PC‌ material, it ensures safety for personnel and equipment.Technical ParametersModel NumberLCB2L-63 2PTypeMCB, RCCB, RCBO, OtherRated Frequency (Hz)50/6···
Request A Quick Quote

General

The ‌LCB2L-63 2P is a Residual Current Circuit Breaker. It features a rated voltage of ‌230/400V‌ and a rated current range of ‌10A-63A‌. Suitable for ‌50/60Hz‌ frequency, it offers protection against electric leaks and is compliant with ‌IEC61008-1‌ standards. Made of ‌PA66/PC‌ material, it ensures safety for personnel and equipment.

Technical Parameters

Model NumberLCB2L-63 2P
TypeMCB, RCCB, RCBO, Other
Rated Frequency (Hz)50/60 Hz
ProtectionLi, Other
Rated current10A-63A
Product nameResidual Current Circuit Breaker
Rated voltage230/400V
CertificateISO9001
ColorWhite
Mechanical Life20000 Times
MaterialPA66/PC
Storage temperature-25~+70
StandardIEC61008-1
