General
The LOVADON RCCB Model LF360 is a high-quality electrical safety device designed for reliable leakage current protection. With rated currents from 6A to 63A and voltage of 230/400V, this white-colored circuit breaker features 2/4-pole configurations and operates at 50/60Hz frequency. Certified to ISO9001 standards, it offers IP20 protection and has a mechanical lifespan of 20,000 operations. Manufactured in Zhejiang, China, this RCCB is ideal for residential and commercial applications where electrical safety is paramount. Its compact design and efficient performance make it a preferred choice for modern electrical installations.
Technical Parameters
| Standard | IEC60898,BS 3871-Pt1 |
| Electrical fcatures | Type(wave form of the earth leakage sensed) |
| A,AC |
| Rated current In | A | 16,25,32,40,63 |
| Poles | P | 2,4 |
| Rated voltage Ue | V | 240/415 |
| Rated sensitivity I△n | A | 0.01,0.03,0.1,0.3,0.5 |
| Insulation voltage Ui | V | 500 |
| Rated residual making and |
|
|
| breaking capacity I△m | A | 630 |
| Short-circuit current I△c | A | 45,006,000 |
| SCPD fuse | A | 6000 |
| Rated frequency | Hz | 50/60 |
| Pollution degree |
| 2 |
| Mechanical features | Electrical life | t | 4000 |
| MechanicaI Iife | t | 20000 |
| Protection degree |
| IP20 |
| Ambient temperature |
|
|
| (with daily average ≤35℃ ) | ℃ | -25℃ ~+40℃ |
| Storage temperature | ℃ | -25℃ ~+70℃ |
Yueqing Lovadon Electric Co., Ltd.
