General
The Time Relay C61F-GP originates from Zhejiang, China. It employs the electromagnetic principle and is designed for delay control applications. This miniature relay features plastic protection and has an insulation resistance of over 100MΩ. It operates within a temperature range of -10°C to 55°C and can be stored between -25°C and 70°C. Ideal for precise and reliable delay control in various electrical systems.
Technical Parameters
| Model Number | C61F-GP |
| Contact Load | medium power |
| Place of Origin | Zhejiang, China |
| Theory | mainly use electromagnetic principle |
| application | It is used for delay control |
| Size | Miniature |
| Protect Feature | with plastic protection |
| Product name | Time Relay |
| Working Temperature | -10°C~ + 55°C |
| Storage Temperature | -25°C~ +70°C |
| Insulation Resistance | > 100MΩ |
Yueqing Lovadon Electric Co., Ltd.
