General
LSC AC contactor is suitable for using in the circuits voltage to 660V 50Hz or 60Hz, rated curent up to 150A, forTheproducts havethe features like small volume, ight weight, lowwer consumption, high eficiency, safety, reiability etc.They can be connected to relaysto control all kinds of electric device, motors and circuits, They can be combinedtogether with auxiiary contact group, air delayer. mechanical interlocking contactors and etc, to constitute delayer. reversible contactor or star-tiangle starter. They also be organized intoelectromagnetic starter bbined with the thermalrelay.
Technical Parameters
| Type | （A）Ratedoperatingcurrent
| （KW）Ratedcontrolledpower | Rated heating current ith（A） |
| 220-240V | 380-440V | 550V | 660V | 220-240V
| 380-440V | 550V | 660V |
| LS-N10 | 2.5 | 4.0 | 4.0 | 4.0 | 11 | 9 | 7 | 5 | 20 |
| LS-N11 | 3.5 | 5.5 | 5.5 | 5.5 | 13 | 12 | 9 | 7 | 20 |
| LS-N12 | 3.5 | 5.5 | 5.5 | 5.5 | 13 | 12 | 9
| 7 | 20 |
| LS-N20 | 5.5 | 11 | 11 | 7.5 | 22 | 22 | 17 | 9 | 32 |
| LS-N21 | 5.5 | 11 | 11 | 7.5 | 22 | 22 | 17 | 9 | 32 |
| LS-N25 | 8.5 | 14 | 14
| 14 | 30 | 30 | 12 | 12 | 40 |
| LS-N35 | 12 | 20 | 20 | 20 | 40 | 40 | 17 | 17 | 40 |
| LS-N50 | 55 | 50 | 26 | 17 | 25 | 30 | 2.8 | 20 | 60 |
| LS-N65 | 62 | 62 | 35 | 19 | 32 | 40 | 2.8 | 20 | 60 |
| LS-N80 | 85 | 85 | 52 | 24 | 40 | 50 | 2.8 | 20 | 60 |
| LS-N95 | 105 | 15 | 65 | 30 | 55 | 60 | 2.8 | 20 | 60 |
| LSC-6N | 37 | 60 | 60 | 60 | 120 | 126 | 90 | 72 | 150 |
